Brembo Corsa Corta Radial Brake Master Cylinder 19 RCS

     0 reviews  |  Write a review
Brands Brembo Brakes
Product Code: 110.C740.10
Availability: In Stock
$372.00

Brembo presents the latest evolution in the radial master cylinder concept with the launch of the new 19RCS CORSA CORTA. This new radial master brake cylinder features a host of innovations, with many of the technical solutions adopted drawn directly from the master cylinders used in MotoGP.
The most significant achievement is, that the 19RCS CORSA CORTA allows the rider to tailor the “bite point” exactly where they want it, with an easily accessible selector on the top of the master cylinder itself (patent-pending technology). The selector operates a cam mechanism to let the user choose between three different responsiveness settings.


In the Normal setting, indicated on the master cylinder with the letter N, the bite point starts more gradually, making it suitable for city riding or braking in poor grip conditions. In the Sport setting, indicated on the master cylinder with the letter S, the beginning of the bite point is shorter than in the N setting. This setting produces a more dynamic response suitable for sportier riding.

Lastly, in the Race setting, indicated on the master cylinder with the letter R, the position of the cam mechanism shortens the initial stage of the bite point even further to produce the same immediate response of the master cylinders used in MotoGP, letting the rider reach the bite point of the brakes instantaneously. This setting is ideal for use on the race track, where every hundredth of a second shaved off a lap time counts.
By simply changing from one setting to another, the rider can configure the braking response and feel of the bike immediately and predictably.

The new Brembo 19RCS CORSA CORTA also features the RCS (Ratio Click System) system introduced 10 years ago on the Brembo 19RCS radial master cylinder, which lets the rider select a fulcrum-to-piston distance of 18 or 20 mm by simply turning the adjuster screw on the front of the guide lever by 180° with a screwdriver. The system uses a cam (red when set to 18 mm, black when set to 20 mm), which adjusts the distance between the fulcrum point and the contact point with the master cylinder push rod by 2 millimeters: this changes the distribution of the braking force without altering the performance of the system in terms of pure power.

The innovative adjustment system introduced with the new Brembo 19RCS CORSA CORTA radial master cylinder contributes to a sense of total control over the bike byletting the rider tailor braking performance to suit their riding style, the weather and road conditions.

A commitment to product improvement has allowed Brembo to offer three different master cylinders in one and to bring the performance of the braking system as a whole to another level. Combined, the choice of two fulcrum-to-piston measurements (18 and 20 mm) and three bite-point settings (R, S and N) offer a total of six different settings.
  • 2009-2017 Aprilia Dorsoduro
  • 2021+ Aprilia RS660
  • 2015-2018 Aprilia RSV4
  • 2009-2014 Aprilia RSV4
  • 2019-2020 Aprilia RSV4
  • 2018-2020 Aprilia SR 50 R
  • 2021+ Aprilia Tuono 660
  • 2015-2020 Aprilia Tuono V4
  • 2017-2020 BMW HP4 Race
  • 2013-2018 BMW R 1200 GS
  • 2015-2016 BMW R 1200 R / R 1200 RS
  • 2014-2019 BMW R nineT
  • 2014-2016 BMW R1200RT
  • 2009-2014 BMW S1000RR
  • 2015-2018 BMW S1000RR
  • 2019-2021 BMW S1000RR
  • 2015-2020 BMW S1000XR
  • 2020 Brixton Cromwell 250
  • 2020 Brixton Felsberg 250
  • 2018-2019 Brixton Glanville 250
  • 2019 Brixton Saxby 250
  • 2002-2007 Buell XB9R / XB12R Firebolt
  • 2007-2009 Ducati 1098
  • 2009-2014 Ducati 1198
  • 2008-2013 Ducati 848
  • 2008-2016 Ducati Desmodesdici
  • 2007-2012 Ducati Hypermotard
  • 2012-2014 Ducati Panigale 1199
  • 2015-2018 Ducati Panigale 1299
  • 2013-2015 Ducati Panigale 899
  • 2016-2018 Ducati Panigale 959
  • 2018-2021 Ducati Panigale V4 / V4 R / Superleggera
  • 2015-2021 Ducati Scrambler Full Throttle
  • 2015-2021 Ducati Scrambler Icon
  • 2015-2021 Ducati Scrambler Sixty2
  • 2020-2021 Ducati Streetfighter V4
  • 2019-2020 Honda CBR 500R
  • 2020-2021 Honda CBR1000RR
  • 2006-2007 Honda CBR1000RR
  • 2008-2011 Honda CBR1000RR
  • 2012-2016 Honda CBR1000RR
  • 2004-2005 Honda CBR1000RR
  • 2017-19 Honda CBR1000RR
  • 2003-2004 Honda CBR600RR
  • 2009-2020 Honda CBR600RR
  • 2005-2006 Honda CBR600RR
  • 2007-2008 Honda CBR600RR
  • 2020 Honda CMX 500 Rebel
  • 2020-2021 CRF1100L Africa Twin
  • 2014-2015 Honda Grom
  • 2017-2020 Honda Grom MSX125
  • 2016-2019 Honda Grom SF
  • 2019+ Honda Monkey 125
  • 2000-2006 Honda RC51 SP1/SP2
  • 2020- Honda SH 125/150
  • 2019-2020 Husqvarna 701 Supermoto
  • 2020- Husqvarna FE 450
  • 2015-2018 Kawasaki Ninja H2 / SX / SE
  • 2020 Kawasaki KX450F
  • 2011-2019 Kawasaki Ninja 1000
  • 1988-2007 Kawasaki Ninja 250
  • 2008-2012 Kawasaki Ninja 250R
  • 2013-2017 Kawasaki Ninja 300R
  • 2018-2020 Kawasaki Ninja 400
  • 2017-2019 Kawasaki Ninja 650
  • 2006-2008 Kawasaki Ninja 650R
  • 2009-2011 Kawasaki Ninja 650R
  • 2012-2016 Kawasaki Ninja 650
  • 2014-2016 Kawasaki Vulcan S 650
  • 2017-2020 Kawasaki Vulcan S 650 / Cafe
  • 2020-2021 Kawasaki Z H2
  • 2011-2018 Kawasaki Z1000
  • 2017-2018 Kawasaki Z125 Pro
  • 2017-2020 Kawasaki Z900RS
  • 2008-2010 Kawasaki Ninja ZX-10R
  • 2011-2015 Kawasaki Ninja ZX-10R
  • 2006-2007 Kawasaki Ninja ZX-10R
  • 2004-2005 Kawasaki Ninja ZX-10R
  • 2016-2020 Kawasaki Ninja ZX-10R / ZX-10RR
  • 2021 Kawasaki ZX-10R / ZX-10RR
  • 2012-2018 Kawasaki Ninja ZX-14R
  • 2006-2011 Kawasaki Ninja ZX-14
  • 2007-2008 Kawasaki Ninja ZX-6R
  • 2009-2012 Kawasaki Ninja ZX-6R
  • 2013-2018 Kawasaki Ninja ZX-6R
  • 2005-2006 Kawasaki Ninja ZX-6R
  • 2019-2020 Kawasaki Ninja ZX-6R
  • 1998-2002 Kawasaki ZX-6R
  • 2020 KTM 1290 SuperDuke R
  • 2020 KTM 390 Adventure
  • 2019-2020 KTM 690 SMC R
  • 2020 KTM 890 Duke R
  • 2020 KTM 890 SuperDuke R
  • 2013-2019 KTM Duke 390
  • 2020 KTM EXC 450 F
  • 2014-2020 KTM RC390
  • 2008-2016 KTM RC8
  • 2020- KTM SX 125
  • 2009-2012 Moto Guzzi V7 Cafe Classic
  • 2017-2020 Moto Guzzi V7 Cafe Classic
  • 2017-2020 Moto Guzzi V7 III
  • 2012-2018 MV Agusta Brutale 675
  • 2015-2018 MV Agusta Brutale 800
  • 2014-2021 MV Agusta Dragster 800
  • 2011-2018 MV Agusta F3 675
  • 2011-2018 MV Agusta F3 800
  • 1999-2004 MV Agusta F4 750
  • 2013-2016 MV Agusta Rivale
  • 2015-2016 MV Agusta Stradale 800
  • 2019-2021 MV Agusta Superveloce
  • All Offroad, Supermoto, Enduro or Motocross
  • 2017-2020 Suzuki GSX-R1000 / 1000R
  • 2007-2008 Suzuki GSX-R1000
  • 2003-2004 Suzuki GSX-R1000
  • 2009-2012 Suzuki GSX-R1000
  • 2012-2016 Suzuki GSX-R1000
  • 2005-2006 Suzuki GSX-R1000
  • 2001-2002 Suzuki GSX-R1000
  • 2011-2020 Suzuki GSX-R600
  • 2008-2010 Suzuki GSX-R600
  • 2006-2007 Suzuki GSX-R600
  • 2004-2005 Suzuki GSX-R600
  • 2001-2003 Suzuki GSX-R600
  • 2006-2007 Suzuki GSX-R750
  • 2004-2005 Suzuki GSX-R750
  • 2008-2010 Suzuki GSX-R750
  • 2011-2020 Suzuki GSX-R750
  • 2017-2020 GSX-S / GSX-R 125
  • 2015-2020 Suzuki GSX-S 1000
  • 2015-2020 Suzuki GSX-S 750
  • 2008-2018 Suzuki Hayabusa
  • 1999-2007 Suzuki Hayabusa
  • 2019-2020 Suzuki Katana
  • 2017-2019 Suzuki SV650
  • 1999-2002 Suzuki SV650 / S
  • 2003-2012 Suzuki SV650 / S
  • 2013-2018 Triumph Daytona 675 / 675R
  • 2006-2012 Triumph Daytona 675 / 675R
  • 2011-2015 Triumph Speed Triple
  • 2016-2018 Triumph Speed Triple
  • 2007-2012 Triumph Street Triple 675
  • 2013-2016 Triumph Street Triple 675
  • 2017-2018 Triumph Street Triple 765
  • 2020+ Triumph Street Triple 765 RS
  • 2014-2021 Yamaha FZ-07 / MT07
  • 2017-2019 Yamaha FZ-09 / MT-09
  • 2013-2016 Yamaha FZ-09 / MT-09
  • 2016-2020 Yamaha FZ-10 / MT-10
  • 2006-2012 Yamaha FZ1
  • 2017-2020 Yamaha SCR 950
  • 2019-2020 Yamaha Tenere 700
  • 2020-2021 Yamaha Tracer 700
  • 2016-2019 Yamaha XSR700
  • 2016-2019 Yamaha XSR900
  • 2014-2016 Yamaha XV 950 R
  • 2020-2021 Yamaha YZ450F
  • 2004-2006 Yamaha YZF-R1
  • 2007-2008 Yamaha YZF-R1
  • 2002-2003 Yamaha YZF-R1
  • 2009-2014 Yamaha YZF-R1
  • 2000-2001 Yamaha YZF-R1
  • 2015-2019 Yamaha YZF-R1
  • 1998-1999 Yamaha YZF-R1
  • 2020-2021 Yamaha YZF-R1
  • 2015-2020 Yamaha YZF-R3
  • 2008-2016 Yamaha YZF-R6
  • 2006-2007 Yamaha YZF-R6
  • 1998-2002 Yamaha YZF-R6
  • 2017-2020 Yamaha YZF-R6
  • 2003-2005 Yamaha YZF-R6
  • 2000 Zonkador SuperGP
